Product Overview
Built for practical production needs
Woven roving is often combined with mat or other reinforcements to balance strength, thickness and surface quality. Areal weight selection depends on structure and process.
Key points
- Bidirectional reinforcement
- Efficient thickness build-up
- Suitable for FRP laminates
- Can be combined with CSM
- Multiple areal weights available
- Basic stack-up support
Lay-up guidance
- Alternate woven roving with CSM to improve interlaminar bonding and reduce resin-rich zones.
- Do not place woven roving directly behind the gelcoat; use CSM or surface mat first to limit print-through.
- Roll thoroughly so resin penetrates the heavy bundles, especially at higher weights.
Applications
Boats, tanks, panels, pipes and FRP structures that need fast thickness build and 0°/90° properties.
Technical note
Specifications and use procedures should be checked against the current TDS/SDS and validated under actual production conditions before full implementation.
Application information
Product position
Bidirectional woven fiberglass
Typical use
Used to increase fiber content and structural performance in hand lay-up laminates and other suitable processes.
Technical confirmation
Areal weight, weave, resin compatibility and part radii must be confirmed before the lay-up is defined.
